WBT1C1CU05(4-20mA Din Rail Mount Signal Converter)uses linear photoelectric isolation technology to isolate and transmit 4mA to 20mA DC current signals. The input, two output and auxiliary power supply of this product are electrically isolated from each other, featuring high accuracy, high isolation, low drift and low power consumption.
Advantages:
27000 square meters non-dust workshop,
30 years' experience,
6 years' application in high speed railway,
ISO, EMC, ETC certificated.
Applications:
Suitable for the current measuring,
Automatic monitoring and control,
Electrical signal detection and modulation,
Data acquisition.
Pictures of Company
Mianyang Weibo Eelctronic Co.,Ltd is a high-tech enterprise established in 2000. The company is engaged with businesses of R & D, manufacturing and supply of electrical sensors/transducers both with analog output and digital output.
The company is located in Mianyang City, Sichuan Province, covers an area of 2.7 hectares. Over the years, the company has paid great attention to the building the R & D and independent innovation capacities and is determined to climb the new peak of measurement and control technology.
The company strives for survival by quality, takes the image of honesty and trust, expands the market with service, and insists on the core value of "innovation, trust, efficiency and responsibility", with creating the "China first and world-renowned" brand as its corporate development goal, and is determined to climb the new peak of measurement and control technology.
Hot Tags: 4-20ma din rail mount signal converter, China, suppliers, factory, price, 4 20mA Din Rail Mount Signal Converter
Main technical parameters of 4-20mA Din Rail Mount Signal Converter:
1. Input range: One Channel DC 4mA～20mA;
2. Output range: One channel DC 4mA～20mA;
3. Accuracy: class 0.5;
4. Equivalent input impedance:
about 300Ω for power supply 12V DC,
about 500Ω for power supply 24V DC;
5. Linear range: 0% to 120% of nominal input;
6. Response time: 120ms;
7. Overload capability: 2 times the nominal input current for 5s;
8. Maximum load capacity: about 500Ω;
9. Auxiliary power supply: 12V DC or 24V DC;
10. Static current: 30mA;
11. Isolation withstand voltage:
>DC 1kV, 1min between input and output,
>DC 1kV, 1min between power supply and output,
>DC 1kV, 1min between power supply and input;
12. Output ripple: <10mV ;
13. Temperature drift: 150 × 10-6 / ° C;
14. Ambient temperature: 0 ° C ~ 50 ° C.
