WBI414N21(4 to 20mA Output Current Sensor Low Power) adopts the special isolation module for real time measurement of AC current from power grid or circuit.
Exhibitions
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally the goods are not in stock. It takes 3-30 days after payment and it is according to quantity.
Q: Do you offer guarantee for the products?
A: Yes, we offer 12 months warranty to our products for non-man-made reasons.
Hot Tags: 4 to 20mA Output Current Sensor Low Power, China, suppliers, factory, price, Current Sensing Monitoring Instrument, Current Transducer 2A, High Stability, Signal Conditioners, 50V 500V Input Frequency Sensor, True RMS Converter 4 20mA Output
Specifications of 4 to 20mA Output Current Sensor Low Power:
|
Rated input current |
30A, 50A, 80A, 100A, 150A, 200A, 250A, 300A, 350A, 400A AC |
|
Output signals |
0-20mA ,4-20mA DC |
|
Accuracy level |
0.2% |
|
Responding Time |
300ms |
|
Frequency range |
25Hz～5kHz |
|
Power supply |
+12V, +15V, +24V DC |
|
Thermal drift |
150ppm/°C |
|
Ambient temperature |
-10℃～+50℃ |
|
Mounting type |
DIN rail 35mm mount or screw mount |
|
Material of shell |
ABS (According to UL94V-0) |
|
Protection of shell |
IP20 |
|
Shell type |
With aperture Ф20mm |
|
Weight |
120g |
