WBI414F23(50-500A Input Current Transducer Arduino) converts AC input current into output signal DC 4-20mA. It has adopted electromagnetic isolation principle for real time measurement of AC current from electric net or electric circuit.
|
Applications Suitable for the current monitoring and measuring; Automatic monitoring and control; Electrical signal detection and modulation; Data acquisition. |
Advantages: 27000 square meters non-dust workshop, 30 years' experience, 8 years' application in high speed railway, ISO, EMC, ETC certificated. |
Caution:
1. Pay attention to the auxiliary power information, especially the auxiliary power grade, and polarity, other wise will damage the product.
2. Pay attention to the wire connection; wrong terminal connection will cause malfunction of the product and even damage the product;
3. Don't dismantle the product, and carry with care to avoiding bump and fall of the product;
4. If the product has been using under the environment with strong magnetic field interference, please pay attention to the shield of input wire, and the output signal wire should be as short as possible. For product intensive installation, the space between each product should not be smaller than 10mm.
5. Only use identified terminals.
6. There is no lightening strike prevention circuit design in this product. For out door and hazardous environment using, please add protective alternatives.
7. This product uses fire prevent ABS crust, its temperature withstand is only limited as +85℃, higher than this limitation will cause the product deformation. Please use and store carefully.
Our company
Mianyang Weibo Electronic Co., Ltd. is a leading provider of measurement and control solutions in China. The company is committed to providing customers with innovative products, services and solutions that meet customers' needs, creating long-term value and potential growth for customers.
The company strives for survival by quality, takes the image of honesty and trust, expands the market with service, and insists on the core value of "innovation, trust, efficiency and responsibility", with creating the "China first and world-renowned" brand as its corporate development goal, and is determined to climb the new peak of measurement and control technology.
Hot Tags: 50-500A Input Current Transducer Arduino, China, suppliers, factory, price, 50-500A Input Current Sensor Arduino, DC Current Transducer Hall Effect, 10mV-1000V Input, LCD Display Multi Circuit Meter, 10V-500V Input AC Voltage Transducer, 0-10V Output DC Voltage Transducer
Input Range: AC 0~50A…0~500A
Output Range: DC 4-20mA
Auxiliary Power: DC +12V/+24V
Frequency Range: 25Hz～5kHz
Accuracy Class: 0.5%
Responding Time: 300ms
Drifting by Temperature: 3.5×10-4/℃
Ambient Temperature: 0℃～+50℃
Mounting Type: DIN rail 35mm mount or screw mount
