WBV342U01-S (DC 10mV-1000V Input Voltage Converter) converts the input DC power supply into a self-contained output voltage of DC voltage 0-5V or 0-10V. DC 10mV-1000V Input Voltage Converter uses a standard descriptive separation circuit and an intermediate meter to measure the DC voltage across the power supply and rotation time.
Advantages:
Complete galvanic isolation of input / output,
High accuracy,
Less drift due to heat,
Wide temperature tolerance.
Application:
Suitable for current measurement
Automatic monitoring and control,
Electrical signal detection,
Written information.
Our company
Mianyang Weibo Electronic Co., Ltd. is a leading provider of measurement and control solutions in China. The company is committed to providing customers with innovative products, services and solutions that meet customers' needs, creating long-term value and potential growth for customers.
The company strives for survival by quality, takes the image of honesty and trust, expands the market with service, and insists on the core value of "innovation, trust, efficiency and responsibility", with creating the "China first and world-renowned" brand as its corporate development goal, and is determined to climb the new peak of measurement and control technology.
Hot Tags: dc 10mv-1000v input voltage converter, China, suppliers, factory, price, 3 Phase 4 Wire, Voltage Sensor, CE Certification, 75mV 500V Input DC Voltage Transducer Max 500V , 10mV 1000V Input, DC Voltage Sensor with Analog Output
Attribute of DC 10mV-1000V Input Voltage Converter:
|
Rated input voltage |
10mV, 75mV, 5V, 50V, 100V, 200V, 300V, 400V, 500V, 750V, 1000V DC |
|
Output signals |
0-5V ,0-10V DC |
|
Accuracy |
0.2% |
|
Input impedance |
Approximate zero |
|
Responding time |
350ms |
|
Linear measuring range |
0 - 1.2 times of rated input current |
|
Power supply |
+12V, +24VDC |
|
Isolation voltage |
≥2500V DC, for 1 minute |
|
Thermal drift |
200ppm/°C |
|
Ambient temperature |
-25℃～+70℃ |
|
Mounting type |
DIN rail 35mm mount or screw mount |
|
Material of shell |
ABS (According to UL94V-0) |
|
Protection of shell |
IP20 |
|
Protection class |
Surge: 2kV; Electrostatic discharge: 6kV/8kV; Electrical fast transient burst: 2kV. |
|
MTBF |
>50000h |
|
Weight |
90g |
